TYPE-U Baffle Grease Filter

High efficiency, low volume baffle grease filter for commercial kitchen exhaust canopy hoods

● Specifically designed for commercial cooking hoods

● Superior grease impingement of even smallest grease particles

● Self-balancing air flow throughout the entire length of the hood

● Low static pressure ensures quiet operation

● Safe, dependable flame barrier protection

● Bail handles standard for easy installation, removal

● Locking handles available as option

● NSF and UL/ULC listed

Model #	Description
U-1016	Baffle Filter, Type U, Stainless Steel, 10" x 16" (254mm x 406mm)
U-1020	Baffle Filter, Type U, Stainless Steel, 10" x 20" (254mm x 508mm)
U-1216	Baffle Filter, Type U, Stainless Steel, 12" x 16" (305mm x 406mm)
U-1220	Baffle Filter, Type U, Stainless Steel, 12" x 20" (305mm x 508mm)
U-1616	Baffle Filter, Type U, Stainless Steel, 16" x 16" (406mm x 406mm)
U-1620	Baffle Filter, Type U, Stainless Steel, 16" x 20" (406mm x 508mm)
U-1625	Baffle Filter, Type U, Stainless Steel, 16" x 25" (406mm x 635mm)
U-2016	Baffle Filter, Type U, Stainless Steel, 20" x 16" (508mm x 406mm)
U-2020	Baffle Filter, Type U, Stainless Steel, 20" x 20" (508mm x 508mm)
U-2025	Baffle Filter, Type U, Stainless Steel, 20" x 25" (508mm x 635mm)
U-2516	Baffle Filter, Type U, Stainless Steel, 25" x 16" (635mm x 406mm)
U-2520	Baffle Filter, Type U, Stainless Steel, 25" x 20" (635mm x 508mm)

MATERIAL: Stainless Steel201/304/430 ,Galvanized, Aluminum
