TYPE-M Baffle Grease Filter

● Designed specifically for commercial kitchen exhaust systems to provide safe, dependable, and positive flame barrier protection.

● Seamless, ridged baffles maximize grease retention while minimizing airflow restriction for superior performance over smooth baffles.

● Low static pressure ensures quiet operation.

● Drop handles included for safe handling, ease of installation, and simple removal for cleaning.

● Easily cleaned and dishwasher safe.

● UL/ULC Listed and certified in the United States and Canada.

● NSF approved and certified.

● Fire Code Compliant and meets NFPA (National Fire Protection Association) fire code standards.


Model #DescriptionActual Size (inch) H x W x D
tYPE m1016Baffle Filter, Type M, Stainless Steel, 10" x 16"9-1/2X15-1/2X1-3/4
tYPE m1020Baffle Filter, Type M, Stainless Steel, 10" x 20" 9-1/2X19-1/2X1-3/4
tYPE m1216Baffle Filter, Type M, Stainless Steel, 12" x 16"11-1/2X15-1/2X1-3/4
tYPE m1220Baffle Filter, Type M, Stainless Steel, 12" x 20"11-1/2X19-1/2X1-3/4
tYPE m1616Baffle Filter, Type M, Stainless Steel, 16" x 16"15-1/2X15-1/2X1-3/4
tYPE m1620Baffle Filter, Type M, Stainless Steel, 16" x 20"15-1/2X19-1/2X1-3/4
tYPE m1625Baffle Filter, Type M, Stainless Steel, 16" x 25"15-1/2X24-1/2X1-3/4
tYPE m2016Baffle Filter, Type M, Stainless Steel, 20" x 16"19-1/2X15-1/2X1-3/4
tYPE m2020Baffle Filter, Type M, Stainless Steel, 20" x 20"19-1/2X19-1/2X1-3/4
tYPE m2025Baffle Filter, Type M, Stainless Steel, 20" x 25"19-1/2X24-1/2X1-3/4
tYPE m2516Baffle Filter, Type M, Stainless Steel, 25" x 16"24-1/2X15-1/2X1-3/4
tYPE m2520Baffle Filter, Type M, Stainless Steel, 25" x 20"24-1/2X19-1/2X1-3/4


MATERIAL: Stainless Steel201/304/430 ,Galvanized, Aluminum
